K9SWX

TV DXing with an indoor antenna

by

I’ve always been fascinated by picking up distant stations whether it’s on the ham band, shortwave or more recently TV. I live on the first floor of an apartment building with no ability for outdoor antennas so I figured my DX opportunities were limited. I’ve tried numerous indoor antennas from the flat thin things that hang in a window to the amplified square boxes. None really brought the channels in that I wanted to watch. Most of our stations are to the west-southwest of me which is great as there is a window on that side of the apartment. The problem is Fox and ABC are in the northeast and east directions which are blocked by walls and other apartment buildings.

TV Fool report from my location in Champaign, IL

My only remote shot at them is going for the Springfield, IL stations which are 65 miles away. Impossible with an indoor antenna? I don’t give up that easily! I originally tried my old Terk HDTVi (non-amplified) antenna. Sure, it’s bulky but it’s very directional which in my case helps. I was able to pick up the stations in Springfield, but they were in and out. I decided to spring for the Terk HDTVa amplified version of the antenna and I now consistently get stable signals from the Fox and ABC stations now pointed out a west window.

Terk HDTVa amplified indoor antenna

I started doing morning channel scans last summer and to my surprise, I picked up 3 stations out of St. Louis, MO which is just over 150 miles away from here. Some days they were just as strong as some of our local stations! I also managed to pick up WTJR out of Quincy, IL which is 161 miles away. Pretty exciting for an indoor antenna! I figured that was the limit of my minimal indoor setup until last week.

I woke up earlier than normal and decided to do a channel scan. I noticed it picked up 1 new channel that I’d never seen. I was thinking it was somewhere in St. Louis since the callsign started with a K rather than a W. It claimed to be KDCU. I looked it up and it said it was in Derby, KS.

My first thought was this was some receiver issue and it was misidentifying some local station. At first it wasn’t strong enough to show a picture. I left it on just for kicks while I had some breakfast and saw the picture blink a few times like it was starting to decode. I was able to make out 4 letters on the screen which said KDCU. Holy crap! 522 miles away on an indoor antenna!

Seeing how no one would ever believe me, I grabbed my cell phone and took a picture of the screen. I asked around on the WTFDA forum and I wasn’t the only one in Illinois to pick it up. An automated receiver northeast of me in Milford, IL also picked it up and they have a slightly better antenna than I do. 🙂

Propagation map during my reception of KDCU in Derby, KS.
6/22/2017 – KDCU-TV in Derby, KS (522 miles)

So this made me wonder how much I am missing when I’m not able to sit and do channel scans all day. I started looking into automated options and everyone seems to use a variation of the HDHomerun receivers. I just ordered the HDHomerun Connect and it should be here later this week so we’ll see what sort of stations we can pick up when I’m asleep or not here to scan manually.

Anyone else do any TV DXing? What gear do you use? What’s the best distance you have achieved?

Samlex 1223 power supply noise

by

samlex1223-2

I’ve had a Samlex SEC 1223 – 23 amp power supply for many years now and it has always made a strange noise. I have two Uniden BC350A scanners hooked up to it that I use to stream local repeaters to Radio Reference / Broadcastify.

I decided to record the noise with my digital audio recorder so I could get some feedback from others on what it might be. It starts in the off position and then you hear me flip the switch on and then off again. (ignore the background noise of my furnace)

If you have any ideas what it is or how to fix it, please let me know. Thanks!

Icom 880H D-STAR radio GPS setup

by

Garmin GPS 18x PC
I’m slowly rebuilding my ham radio shack after getting rid of everything a few years ago. One of the things I missed the most was the trusty dual band rig in the car. I decided to sell my iPad to help fund the radio purchase. I couldn’t afford a brand new rig, so I looked at the ham classified sites to see what was available. I settled on the Icom 880H 2m/70cm mobile rig. One thing that intrigued me about this setup was the fact that it has D-STAR capability built into it. We have a growing D-STAR network here in Illinois so it seemed like a good idea to have a radio with D-STAR.

When I got the rig, I tried programming a few repeaters in manually just to see if I could do it. The analog frequencies weren’t too difficult, but D-STAR was a bit more difficult. I figured it would be a good idea to program it with the computer, so I ordered the OPC-1529R data cable. I know most folks prefer the RT Systems software, but I decided to try the free Icom programming software instead.

It’s a pretty basic program, but it gets the job done. The problem is there is no way to directly import frequencies from sites like RepeaterBook and RFinder. There is another free programming software called CHIRP that lets you import from these sites. However, getting it from CHIRP into the Icom software is very clunky.

I finally decided to go to the Illinois Repeater Association website and copy/paste the repeaters into a text file. I then opened it in a spreadsheet program called LibreOffice Calc (Microsoft Office works as well) which then lets me sort and filter by regions of the state. Now this still doesn’t let me import into the Icom software. I ended up putting the spreadsheet on one side of my screen and the Icom software on the other and manually typing in the repeaters that I wanted. It’s a time consuming process but at least I can put the frequencies where I want them in the radio.

I have the radio plugged into my Comet CA2X4SR dual band antenna mounted on the door with a Diamond K400 mount. I’ve had this antenna hooked up to other radios over the years and it works great with the 880H. Another nice thing is the radio has a weather alert that lets you know when bad weather is approaching. It also scans air frequencies which are fun to listen to once in a while.

One thing I’ve missed that my old Kenwood D700A had is the APRS functionality. There is a way to get your position on the Icom 880H to the APRS network, but you need to add a GPS to the radio. (most of the other D-STAR radios have GPS built in) I chose the Garmin GPS 18x PC for my setup. It’s a very basic GPS unit with a 12v cigarette plug and 9-pin serial port on it. You hook it up to the Icom 880H with a null modem adapter.

There’s a few things in the radio you need to change before the GPS will work. The first is the data speed which defaults to 9600 bps. You need to change it to 4800 bps for it to work with the GPS 18x unit. Go into the SET menu, then FUNC and then SPEED and change it to 4800. If everything is hooked up properly, you will see the GPS indicator in the top right start blinking indicating it sees your GPS. When it has acquired a good satellite lock, the indicator will stay on.

Another thing you need to change for it to work with APRS is the GPS-TX mode. It defaults to DVG, but needs to be on DVA. It’s in the GPS –> GPS-TX menu. Inside that menu you’ll also want to change your symbol (the icon that shows up on the APRS map), add a comment and enable the direction/speed (DT EXT –> CUR.SPD) if you want that to show up.

You can see my position on the APRS network:
http://aprs.fi/#!call=a%2FK9SWX

Please note that your position will only show up on APRS when you push the PTT button on the microphone. You can set it up to automatically send it every so often, but that is highly frowned upon. (especially if the repeater is linked to a reflector or another repeater.)

I’ve put together a little video about my Icom 880H. Check it out and let me know what you think!

Parts list

    • Note: Some of these links below are affiliate links which means if you purchase the item I will get a commission from the sale.

Please let me know if you have any questions about all of this. Thanks! 73..

Stan – K9SWX

Shortwave radio itch

by

Before getting into ham radio, I really enjoyed listening to shortwave radio. My first rig was a Realistic DX-300. Later on, my parents bought me a Radio Shack DX-392 radio. The nice thing about this radio was that it had SSB capability so I could listen to hams and other SSB signals. It also had a cassette recorder and could record programs automatically while you were away. One of my favorite stations to listen to back in the day was HCJB: The Voice of the Andes in Quito Ecuador. I remember corresponding with host Allen Graham who read some of my letters on his shows. Sadly they ceased shortwave transmission in 2009. (If anyone knows of a website that archived their recordings, please let me know!)

Last month while I was visiting my parents, I asked if they still had the DX-392. Sure enough, it was easily found and it came home with me. I live in an apartment, so getting any signals was going to be a challenge. I tried using the built-in telescopic whip, but that was futile with all the interference in the building. I then decided to string up a wire from one end of the apartment to the other which faces the outside wall. Using an alligator clip, I attached the wire to my whip and started picking up signals.

Last weekend I stopped by Barnes and Noble to see if they had any shortwave books. I dug around and found the World Radio TV Handbook 2014 book in the science section. I thumbed through it and was impressed with all the information, so I purchased it.

There is something about spinning the dial and researching where a signal is coming from that makes the hobby fun. Between the WRTH 2014 book and various online resources, it is pretty exciting to figure out what you are hearing.

Anyone else into shortwave radio? Are you using a dedicated receiver or one of your ham rigs? Any tips for indoor antennas?

2011 CQWW SSB contest

by

I took a little drive today to my favorite park outside of town to work a few stations in the CQWW contest. I usually don’t work very many contests, but anytime I hear lots of stations on 10m I just have to try a few QSOs. Using the FT-857D in the mobile at 100w and ATAS120A antenna, I was easily working DX. In a short period of time, I worked SN3R (Poland), IR8C (Italy), GW9T (Wales), G5O (England) and F5TTI (France). I setup the video camera and captured these contacts. (sorry about the shaky shots, should have used the tripod)
