Icom 880H D-STAR radio GPS setup

Garmin GPS 18x PC
I’m slowly rebuilding my ham radio shack after getting rid of everything a few years ago. One of the things I missed the most was the trusty dual band rig in the car. I decided to sell my iPad to help fund the radio purchase. I couldn’t afford a brand new rig, so I looked at the ham classified sites to see what was available. I settled on the Icom 880H 2m/70cm mobile rig. One thing that intrigued me about this setup was the fact that it has D-STAR capability built into it. We have a growing D-STAR network here in Illinois so it seemed like a good idea to have a radio with D-STAR.

When I got the rig, I tried programming a few repeaters in manually just to see if I could do it. The analog frequencies weren’t too difficult, but D-STAR was a bit more difficult. I figured it would be a good idea to program it with the computer, so I ordered the OPC-1529R data cable. I know most folks prefer the RT Systems software, but I decided to try the free Icom programming software instead.

It’s a pretty basic program, but it gets the job done. The problem is there is no way to directly import frequencies from sites like RepeaterBook and RFinder. There is another free programming software called CHIRP that lets you import from these sites. However, getting it from CHIRP into the Icom software is very clunky.

I finally decided to go to the Illinois Repeater Association website and copy/paste the repeaters into a text file. I then opened it in a spreadsheet program called LibreOffice Calc (Microsoft Office works as well) which then lets me sort and filter by regions of the state. Now this still doesn’t let me import into the Icom software. I ended up putting the spreadsheet on one side of my screen and the Icom software on the other and manually typing in the repeaters that I wanted. It’s a time consuming process but at least I can put the frequencies where I want them in the radio.

I have the radio plugged into my Comet CA2X4SR dual band antenna mounted on the door with a Diamond K400 mount. I’ve had this antenna hooked up to other radios over the years and it works great with the 880H. Another nice thing is the radio has a weather alert that lets you know when bad weather is approaching. It also scans air frequencies which are fun to listen to once in a while.

One thing I’ve missed that my old Kenwood D700A had is the APRS functionality. There is a way to get your position on the Icom 880H to the APRS network, but you need to add a GPS to the radio. (most of the other D-STAR radios have GPS built in) I chose the Garmin GPS 18x PC for my setup. It’s a very basic GPS unit with a 12v cigarette plug and 9-pin serial port on it. You hook it up to the Icom 880H with a null modem adapter.

There’s a few things in the radio you need to change before the GPS will work. The first is the data speed which defaults to 9600 bps. You need to change it to 4800 bps for it to work with the GPS 18x unit. Go into the SET menu, then FUNC and then SPEED and change it to 4800. If everything is hooked up properly, you will see the GPS indicator in the top right start blinking indicating it sees your GPS. When it has acquired a good satellite lock, the indicator will stay on.

Another thing you need to change for it to work with APRS is the GPS-TX mode. It defaults to DVG, but needs to be on DVA. It’s in the GPS –> GPS-TX menu. Inside that menu you’ll also want to change your symbol (the icon that shows up on the APRS map), add a comment and enable the direction/speed (DT EXT –> CUR.SPD) if you want that to show up.

You can see my position on the APRS network:
http://aprs.fi/#!call=a%2FK9SWX

Please note that your position will only show up on APRS when you push the PTT button on the microphone. You can set it up to automatically send it every so often, but that is highly frowned upon. (especially if the repeater is linked to a reflector or another repeater.)

I’ve put together a little video about my Icom 880H. Check it out and let me know what you think!

Parts list

    • Note: Some of these links below are affiliate links which means if you purchase the item I will get a commission from the sale.

Please let me know if you have any questions about all of this. Thanks! 73..

Stan – K9SWX

Shortwave radio itch

Before getting into ham radio, I really enjoyed listening to shortwave radio. My first rig was a Realistic DX-300. Later on, my parents bought me a Radio Shack DX-392 radio. The nice thing about this radio was that it had SSB capability so I could listen to hams and other SSB signals. It also had a cassette recorder and could record programs automatically while you were away. One of my favorite stations to listen to back in the day was HCJB: The Voice of the Andes in Quito Ecuador. I remember corresponding with host Allen Graham who read some of my letters on his shows. Sadly they ceased shortwave transmission in 2009. (If anyone knows of a website that archived their recordings, please let me know!)

Last month while I was visiting my parents, I asked if they still had the DX-392. Sure enough, it was easily found and it came home with me. I live in an apartment, so getting any signals was going to be a challenge. I tried using the built-in telescopic whip, but that was futile with all the interference in the building. I then decided to string up a wire from one end of the apartment to the other which faces the outside wall. Using an alligator clip, I attached the wire to my whip and started picking up signals.

Last weekend I stopped by Barnes and Noble to see if they had any shortwave books. I dug around and found the World Radio TV Handbook 2014 book in the science section. I thumbed through it and was impressed with all the information, so I purchased it.

There is something about spinning the dial and researching where a signal is coming from that makes the hobby fun. Between the WRTH 2014 book and various online resources, it is pretty exciting to figure out what you are hearing.

Anyone else into shortwave radio? Are you using a dedicated receiver or one of your ham rigs? Any tips for indoor antennas?

2011 CQWW SSB contest

I took a little drive today to my favorite park outside of town to work a few stations in the CQWW contest. I usually don’t work very many contests, but anytime I hear lots of stations on 10m I just have to try a few QSOs. Using the FT-857D in the mobile at 100w and ATAS120A antenna, I was easily working DX. In a short period of time, I worked SN3R (Poland), IR8C (Italy), GW9T (Wales), G5O (England) and F5TTI (France). I setup the video camera and captured these contacts. (sorry about the shaky shots, should have used the tripod)

Working Spain from the mobile

While I was running some errands yesterday, I decided to tune around the HF bands to see how conditions were doing. I noticed numerous DX stations on 10 meters, but wasn’t sure they’d hear my little mobile station. I stumbled across EA1DR (Oscar) in northern Spain who was coming in pretty strong. I pulled over into a parking lot and tried answering his CQ DX call numerous times, but to no avail. I pulled out of the parking lot and decided to try him one more time. Success! It was a short 30 second contact, but he said my mobile station was doing a great job into Spain. Amazing how one little contact like this can brighten up my day.

Something I’ve been trying to do more of is recording the audio of my HF QSO’s, at least the DX ones. I remembered to hit the record button on my iPhone audio app and captured this nifty QSO.

EA1DR
10-06-2011-EA1DR

Champaign IL ham radio repeater stream

scannerstream1
I recently got a wild hair to stream some ham radio audio. I’m already familiar with the streaming process as I stream the Champaign, Illinois NOAA weather radio on Wunderground. My plan was to run a stereo feed with the left channel going to one repeater and the right channel going to the other repeater.

I found a decent deal on some Bearcat BC350A’s on eBay, so I purchased 2 of them. I debated on adding a second sound card to the computer streaming the weather radio, but decided it’d be easier to just use a second computer. Luckily I had an old Dell Optiplex GX260 here that would be suitable for streaming. I have the scanners hooked up to my old Samlex 1223 power supply. I had mixed feelings if this would even work as it had some issues with the HF rig, but so far it’s been running great. The antenna setup is tricky since I am unable to put up anything outside.

The scanners came with a simple window mount antenna with suction cups, but the gear was too far from any windows. When I first tested the audio, the signals would fade in and out and they were picking up interference from surrounding electronics. I did some research on splitting antenna signals and decided to go the cheap route. I found some RG6 quad shielded coax and used that to stretch across the room to the window. I have that hooked up to a 4-way cable TV splitter. I have several adapters converting from F to BNC. Some folks say that will cause a lot of signal loss, but in my situation it shouldn’t matter too much. I live within a mile of the tower that the repeaters are located on, so the using suction cup antenna in the window should suffice.

I decided to use Radio Reference to stream my feed. They mainly focus on public safety feeds, but they also allow ham repeaters on their network. Basically I send my stream to their servers and they stream it to whoever wants it. They can support tons of traffic vs me trying to run the feed from my home DSL line. I was hoping to get my feed approved ASAP as we were expecting some severe weather during the week.

I was approved on May 23rd and went live in the morning on May 24th. On May 25th, we were expecting some nasty weather. One of the repeaters on my stream is the local ARES repeater which runs weather nets as needed. Sure enough, we were under a tornado watch and even had a tornado spotted outside of Champaign. I checked the stats afterwards and discovered I had 35 visitors during that time. That made me feel like my efforts to get the stream going were put to good use.

As mentioned earlier, the stream consists of 2 repeaters split across the left and right channels. That is, you’ll hear one repeater on the left speaker and the other on the right speaker. The repeater on the left is the K9CU repeater on 146.760 Mhz. This repeater is connected to Echolink and is a general purpose repeater. It has a weekly Thursday night net open to all ham operators. (9pm local time) The repeater on the right is the K9SI repeater on 444.100 Mhz. This repeater is the Champaign County ARES repeater which runs the weather nets. They also have a weekly Tuesday night net for both ARES members as well as any other hams who wish to check in. (9pm local time)

There are several Android and iPhone apps that interface with the Radio Reference streams. There is one app for iPhone called 5-0 Radio that has my stream available. If you want more details on the stream, here is the link to my feed page at Radio Reference:

K9CU 146.760 Mhz and K9SI 444.100 Mhz Amateur Repeaters

If you have any questions about the stream that I didn’t cover, please post them in the comments section. Thanks!
